Spring Return Actuators - VT-S Series
SPECIFICATIONS
| Torque Output |
Minimum | : | 50 N.m |
| Maximum | : | 260 N.m | |
| Enclosure | : | NEMA 4X / IP67 | |
| Temperature Range | : | -30˚C ~ +65˚C -22˚F ~ +149˚F |
|
| Power Supply | : |
24VDC, 1Ph 110V / 220V, 3Ph 380V / 440V |
|
CERTIFICATIONS
Features
All models have continuous mechanism position indicator on the top actuator cover.
Gear trains lubricated sufficiently with anti-high temperature.
The actuator complies with NEMA 4x (IP 67) standard, water proof and dust-proof enclosure.
Manual override with handwheel in option.
ATEX and CSA Certified for hazardous and explosion proof area.
| Document | Type | Download |
|---|---|---|
| Spring Return Electric Actuator | English |
